TL6V18W85/145V
TL6V18W175/285V

IP66 LED tube with its integrated driver, practical for poultry cage applications.

This will allow you to achieve considerable savings in terms of energy consumption and maintenance costs.

Product codeTL6V18W85/145V | TL6V18W175/285V
DesignationV-Shape waterproof LED tube 18W
StructureRobust molded plastic with polycarbonate optics and polymer cable gland
Dimensions6’
Washablewith up to 1500 PSI steam pressure at a temperature up to 200° F
LED diode brandSamsung
Consumption18W
Light power2 340 lm
Luminous efficiency130 lm/W
Dimmable0,2% to 100%
Color T°3000K, 4000K, 6500K
Color rendering index≥83
OpticalClear
Beam angle220°
% flicker of non-visible light<4%
IP water protection indexIP 66
IK impact protection classIK 08
Power factor0.95
Total harmonic distortion (THD)<15%
Maximum ambient T°-20°c / +50°c
Supply voltage / Frequency85/145V (175/285V on demand) / 50/60Hz
Lifetime / Warranty≥80 000h / 5 years
Certifications
